SEMI AUTOMATIC ROPP/SCREW CAP SEALING MACHINE
DESCRIPTION

The semi automatic cap sealing machine is precision built on sturdy welded steel Frame completely encloses in stainless steel sheet.

Machine operator bring container along with cap below the rotating head. Sealing Head automatically comes down and does operation of threading and sealing.

TECHNICAL SPECIFICATION *
Model No DACS25
Output 2400 Containers (Depending on bottle size and operator skill)
Electrical Rating 0.5 HP / 440 Volts / 3 phase / 50 Hz (Four Wire) For Main Machine
Container Size 22 mm to 100 mm
Height of container 50 mm to 210 mm Maximum, Option for other bottle Height available
Cap Size 22 mm to 56 mm (With the help of required change parts).
Overall Dimensions 575 (L) * 575 mm (W) * 1500 (H) Approx
    UNIQUE FEATURE
    • S.S. Elegantly Matt Finished Body
    • Easy to operate
    • Easy to maintain
    • Built in front control panel
    • The unit is made compact and versatile
    * Note : We reserve the right to change specification without prior notice.
