SEMI AUTOMATIC LIQUID FILLING MACHINE
DESCRIPTION

Compact, Versatile and enclosed in stainless steel elegantly matt finish body. Having Most of the features of automatic machine The basic unit consist of filling Nozzles, S.S. container platform, Container Centering device, Syringe Holders, HDPE Tubes and pipes and on line starter.

Two containers are manually placed on to the container platform, which is accurately centered initially for one size of container. Machine nozzles automatically fill container as per pre-set fill volume. Filled containers are removed manually and replaced by empty ones

TECHNICAL SPECIFICATION *
Model No DLF25
Output / minutes 500 to 1500 Containers
Fill Size 10 ml to 2000 ml (With the help of required change parts)
Container Size Diameter: 30 mm to 100 mm Maximum Height : 210 mm maximum
Electrical motor Machine 0.5HP / 440 Volts / 3 Phase /50 Hz (Four wires)
Overall Dimensions 640 mm (L) * 755 mm (W) * 680 mm (H)
    UNIQUE FEATURE
    • The unit is made compact & versatile.
    • S.S. Elegantly Matt Finished Body
    • S.S. filling nozzles with self-centering device
    • The unit can be quickly dismantled for maintenance just by opening front cover
    • Each and every part can be attended for cleaning and maintenance easily
    • Suitable for Glass, Plastic, Pet, Aluminum, Tin containers.
    * Note : We reserve the right to change Specification without prior notice.
    AUTOMATIC WET GLUE LABELLING
    AUTOMATIC STICKER LABELLING
    AUTOMATIC VOLUMETRIC LIQUID BOTTLE FILLING
