SEMI AUTOMATIC GLUE LABELING MACHINE
DESCRIPTION

Compact, is simple & easy to use machine for sticking paper labels on to various metal, glass or plastic bottles & cans, etc. with automatic glue application.

It can work without any change of machine parts in bottles ranging from 30 ml. To 1 liter which can be brut shaped or mineral water bottles. The machine has automatic feeding of label stack by slant magazine. Works with cold glue & cleaning of glue pan requires no time & skill.

TECHNICAL SPECIFICATION
Model No DSGM
Label Width 30mm to 100mm
Power Supply 415 Volts, 3 Phases
Electrical Rating 0.25HP main motor
Speed 30-35 Bottle/Min Speed. (Depending on the container size and the label size)
Overall Dimensions 700 mm (L) * 400 mm (W) * 560 mm (H)
UNIQUE FEATURE
  • No label data input / retrievals programming require for any label size.
  • No change parts required.
  • Virtually maintenance free machine.
  • Stainless steel 304 construction.
  • GMP Design.
  • User friendly label placing adjustment.
  • Built in A.C. variable frequency drive system.
  • Accurate label placement.
  • In built digital pulse counter.
  • Suitable for Glass, Plastic, Pet, Aluminum, Tin containers.
Note : We reserve the right to change Specification without prior notice.
OPTIONAL FEATURE
  • Printing unit ( 6 bar Air Pressure Required for Printing device )
  • Turn table ( Un Scrambler )
