The conveyor belt is having stainless steel Table top with moving S.S. belt in the center. Tabletop is fixed to the same structure made out Of S.S. square pipe & supported on Moveable Stand. Tabletop is of 12 inches working Space on both sides of the conveyor belt final visual inspection & packing in to the Box.
technical specification
| Model No | DHSL - 150 |
|---|---|
| Machine Construction | Stainless Steel 304 Square Pipe Structure and Cladding with SS304 pvc coated sheet. |
| Electrical rating | Machine Main Motor 0.5 HP |
| Power Supply | 1 Phase / 3 Phase |
| Belt Size | 300mm PVC Belt |
| Height of Conveyor | 860 mm to 910 mm |
| Overall Dimensions | 3050 mm(L) X 850 (W) 910mm (H) |
Salient Features
- Construction AISI S.S. 304 Quality
- Structure S.S. Square Pipe
- 0.5 HP, 3 Phase, 1370 RPM Motor with Gear Box.
- Your Order Should Be For Minimum 10 Feet Length.
- Frequency Variable Drive For Conveyor Speed
